E-F100 Face Time Attendance&Access Control

Face Recognition Time Attendance and Access Control System
Face recognition attendance machine
Face Recognition Time Attendance and Access Control System

8 big function

Face Recognition Time Attendance and Access Control System

4.3 inch
color screen

Face Recognition Time Attendance and Access Control System

face recognition

Face Recognition Time Attendance and Access Control System

usb exported
reports

Face Recognition Time Attendance and Access Control System

Convenient operation
management


Face Recognition Time Attendance and Access Control System

The usb
communication

Face Recognition Time Attendance and Access Control System

The U disk high
speed download

Face Recognition Time Attendance and Access Control System

recording and
querying

Face Recognition Time Attendance and Access Control System

Access control
function


0.1S Quickly recognize faces

Intelligent attendance

Face Recognition Time Attendance and Access Control System

Wear glasses

Face Recognition Time Attendance and Access Control System

twins

Face Recognition Time Attendance and Access Control System

facial makeups

Accurate recognition

Face Recognition Time Attendance and Access Control System

Wear a hat

Face Recognition Time Attendance and Access Control System

Change hair style

Face Recognition Time Attendance and Access Control System

night


Face Recognition Time Attendance and Access Control System
Every detail, we all strive for perfection
Face Recognition Time Attendance and Access Control System

High-definition color screen

4.3 -inch high-definition color screen,
It does not hurt your eye.


Face Recognition Time Attendance and Access Control System

Double Hd camera

Black and white, color dual cameras,The
infrared optical system,It has strongly
adaptability to the environment


Face Recognition Time Attendance and Access Control System

touch control

Screens can touch operation,
Let human-computer interaction
more friendly .


Face Recognition Time Attendance and Access Control System

Infrared identification technology

It uses infrared intelligent identification,
Stable performance. 300 faces capacity.
Don't recognize pictures, only recognize
true face.


Product function parsing
Face Recognition Time Attendance and Access Control System
Face Recognition Time Attendance and Access Control System
Face Recognition Time Attendance and Access Control System Face Recognition Time Attendance and Access Control System

Installation instructions

Hanging installation

On the wall of the apart from the ground 1.15 meters
installed side by side two standard M3 bolts. Two bolt
center distance between 60-70 - mm, center line parallel
to the ground.Install the machine on the back of the two
bolt holes are aligned, will hang up machine



Desktop put to use

Attendance machine adopts the triangle
three-dimensional appearance design, it
can be placed in the front desk on the
desktop or other platforms used directly,
without additional installation

Face Recognition Time Attendance and Access Control System
Item Description
LCD TFT displayer:  4.3inch HVGA high resolution touch screen
Keypad 7 key Touch type + touch screen input
Face capacity 3, 00
Log Storage capacity 200, 000
Verification mode 1: N, 1:1
Response time ≤1 second
Cammera Omni Vision higher resolution 2pcs camera built-in(Infrared&Normal)
External functions Connect Electronic lock(Access Control), Wiegand Output
Communication l USB 2.0 free driver,10M/100M Ethernet USB HOST,RS485
CPU ATMEL ARM9 400MHz
Memory  512Mb
Flash Memory 1 GB
SD card Optional
FRR 1%
FAR 0.00001%
Work mode online, offline
Language display Simplified Chinese, Traditional Chinese, English
Name display Chinese or English Name, User ID, User picture
Communication TCP/IP, RS485, USB
Identification mode face, password,
Temperature/Humidity 0℃~45℃ / 20%~ 80%
Power supply DC12V/2A
Function Key sign in, sign out, go out, ESC key
Lock output often open/often close
Access control interface wiegand 26/34 optional, output/input optional
Warranty of period 12 months
Size 200*90*65mm
Applications Office/factory/bank/hotel/school etc
