EFO-BI161 With Built-in biocolor LED, Antenna & Buzzer, Read 64bits Read-Only uem410 MF1 IC Card, Wiegand 26/ABA Real time output, suit access control, T& A, Payment, Anti-theft
          Reading speed:＜0.2s;                         Read Interval:＜0.5s;
          distance:100m;                                       Working Voltage:12V;
          Current:70mA;                                        Temperature -25℃~75℃;
          Humidity 10%~90%

(1) the reader will be sent out by the antenna carrier signal;
(2) the card into the card reader to read the work area, the resonant circuit is composed of inductance and capacitance in the card receiving card reader launch carrier signal, RF interface module card chip which signals generate power supply voltage, clock reset signal system, make the chip "activation";
(3) the chip reading control module will be the data in the memory phase encoded by the modulation of the carrier, the card back to the card reader antenna;
(4) the reader demodulation and decoding is sent to the background computer or controller for IC received signal;
(5) a computer or controller according to the legitimacy of the card, make appropriate treatment and control for different application.

1. the card reader box sticker on the installing card reader position, press the outlet hole mark location opened two location hole and a middle positioning hole plug, the rubber plug. (Note: if the installation on the wall, concealed need embedded 86 installation box.)
2. the use of a fixed panel and the bottom cross screwdriver unscrew the screws, remove the floor, use screws will bottom plate fixed on the control entrance side walls.
3. the reader thread through the outlet hole, according to the instructions to connect the wire, the reader panel and bottom plate screw fixation.
